Introduction to Positive pressure powder conveying pump, introduction to bin pump function advantages and characteristics

Positive pressure powder conveying pumpis a kind of equipment used for pneumatic conveying, which is mainly used to convey powdery or granular materials to designated places through airflow.，meet the requirements of environmental protection,large conveying capacity,automation,flexible layout,efficient transportation。The following is to introduce the Positive pressure powder conveying pump:

1、Brief introduction of Positive pressure powder conveying pump

Positive pressure powder conveying pumpalso known as sending tank, pneumatic conveying pump or bin pump.，When the material enters the pump body and is full, it is gasified to make the material form a fluidized state and smoothly enter the mixing chamber. At the same time, the compressed air is ejected at high speed through the jet nozzle and fully mixed with the fluid material. The high-speed airflow drives the material to pass through a specific pipeline, which converts the kinetic energy of compressed air into pressure energy, and at the same time, the air and the material are mixed again, so as to improve the speed of the material and make it move forward along the conveying pipeline, thus achieving the purpose of conveying powdery materials.，It has a wide range of uses, and is often used inparticle transport,material handling,pneumatic transport,powder conveying,environmental protection and dust removal and so on，was developed and designed by hyde powder。

Positive pressure powder conveying pump

2、Structural characteristics of Positive pressure powder conveying pump

The Positive pressure powder conveying pump structure is introduced as follows:

1. pump body

The core part of the Positive pressure powder conveying pump is used to contain materials. The pump body is generally a cylindrical pressure vessel, and its material is usually carbon steel or stainless steel to ensure sufficient strength to withstand internal pressure. In the design, the volume of the pump body should be considered, which will be determined according to the actual delivery requirements.

2. Feed valve and discharge valve

The feed valve is used to control the material entering the pump body, and the discharge valve is used to control the material discharging from the pump body. These valves are usually ball valves, butterfly valves or gate valves, which require good sealing to prevent material leakage and gas leakage.

3. Air intake device

Comprises an air inlet pipeline, an air inlet valve and other components. The air inlet pipe is used to introduce compressed air into the pump body, and the air inlet valve can control the flow and pressure of compressed air. The performance of air intake device directly affects the conveying speed and efficiency of materials.

4. pump body

The core part of the Positive pressure powder conveying pump is used to contain materials. The pump body is generally a cylindrical pressure vessel, and its material is usually carbon steel or stainless steel to ensure sufficient strength to withstand internal pressure. In the design, the volume of the pump body should be considered, which will be determined according to the actual delivery requirements.

5. level-sensing device

Used to detect the material level in the pump body. Common level gauges include capacitive level gauges and ultrasonic level gauges. Through the material level gauge, the feeding amount can be accurately controlled to avoid the situation that the pump body is too full or the material is insufficient.

Positive pressure powder conveying pump

3、Positive pressure powder conveying pump characteristics

Positive pressure powder conveying pumpconvenient maintenance,simple operation,efficient transportation,flexible layout,high reliability，the product looks atmospheric.，as an efficient pneumatic conveying equipment，favorable price，reliable quality。

Positive pressure powder conveying pump

4、Positive pressure powder conveying pump characteristics

Positive pressure powder conveying pumpit has the characteristics of simple operation, convenient maintenance, meet the requirements of environmental protection, large conveying capacity and pollution-free transportation。

Positive pressure powder conveying pump

5、Positive pressure powder conveying pump work site real shot

hyde Positive pressure powder conveying pump came in many pictures, which made everyone feast their eyes.。

Positive pressure powder conveying pump

Note: All the pictures in this article were taken by hyde powder manufacturer.。

6、Company discount

Positive pressure powder conveying pump is a new type of bin pump introduced by Shandong Haide Fenti Engineering Co., Ltd. manufacturer, which has a wide range of applications, complete structural design and high working efficiency. It is an ideal equipment for electricity industry and other industries. Now consult Positive pressure powder conveying pump, you can enjoy the discount, and there are many activities for you, such as full reduction and full reduction。

hyde

Positive pressure powder conveying pumpIt can be used for particle transport, pneumatic transport, material handling, pneumatic ash conveying, powder conveying, environmental protection and dust removal and so on，it can be used in Building materials industry, chemical lines, food service industry, Cement industry, chemical lines and other industries，Structure consists of control system, air evacuation valve, fluidizer, bleeder valve, intake valve and so on，productSimple structure and advanced technology.。
