Introduction to Grain granule conveying system and pneumatic conveying system structure principle

Grain granule conveying systemis a comprehensive technology, which involves fluid mechanics, material science, automation technology, manufacturing technology and other fields.。

1、Brief introduction of Grain granule conveying system

Grain granule conveying systemit uses the kinetic energy and pressure energy of air flow to transport materials from the starting point to the destination pipeline.，be of high quality，favorable price。

Grain granule conveying system

2、Grain granule conveying system use

The purpose of Grain granule conveying system is introduced as follows:

1. save energy and cut emissions

Although the Grain granule conveying system system itself needs to consume some energy, compared with other transportation modes, it usually has higher transportation efficiency and lower maintenance cost. In addition, by optimizing the system design and adopting advanced energy-saving technology, energy consumption can be further reduced and the goal of energy saving and emission reduction can be achieved.

2. Mixing and classification

In the process of conveying, the Grain granule conveying system system can cooperate with other equipment to realize the mixing and grading operation of materials, and improve the production efficiency and product quality.

3. cut down on energy consumption

Although the power consumption of the Grain granule conveying system is relatively large, the energy consumption can be reduced by optimizing the system design and selecting efficient equipment, so as to achieve the goal of energy saving and consumption reduction.

4. Bulk material transportation

The Grain granule conveying system is especially suitable for conveying powdery, granular and flowable bulk materials. These materials include, but are not limited to, cement, fly ash, grain, plastic particles, pharmaceutical powder, etc. Through the Grain granule conveying system, these materials can be efficiently transferred between different production links or equipment.

5. Reduce pollution

The Grain granule conveying system system carries out material transportation in a fully enclosed state, which effectively reduces the environmental pollution caused by dust flying and material leakage.

Grain granule conveying system

3、Grain granule conveying system performance advantage

Grain granule conveying systems have the following advantages.

1. Multiple process operations can be carried out at the same time

In the process of conveying, the Grain granule conveying system system can also perform physical operations such as heating, cooling, drying and airflow classification or some chemical operations at the same time, which increases the versatility of the system.

2. Strong adaptability

A conveying system can convey different kinds of products at different times. In fact, all powders and particles can be transported by the Grain granule conveying system.

3. High degree of automation

Modern Grain granule conveying system systems are usually equipped with automatic control equipment, such as PLC control system, sensors, actuators, etc., which can realize remote monitoring and automatic adjustment. This highly automated transportation mode reduces labor costs and improves production efficiency and management convenience.

4. Low maintenance cost

The Grain granule conveying system device has the advantages of simple structure, few moving parts, convenient maintenance and reduced maintenance cost. At the same time, the equipment occupies a small area and can make full use of space.

5. be simple in structure

The structure is relatively simple and the operation is very convenient. It can be transported flexibly in horizontal, vertical or inclined directions to adapt to different production environments.

Grain granule conveying system

4、Grain granule conveying system structure

The Grain granule conveying system structure is introduced as follows:

1. Air source device

The air source device is the power core of the Grain granule conveying system system, which provides the airflow power needed for transportation. Common air source equipment includes roots blower, compressor, centrifugal blower and water ring vacuum pump. These devices can generate stable airflow and provide sufficient power for the transportation of materials.

2. Bunker system

The silo temporarily stores and releases materials. The silo is usually designed as a pyramid or conical structure to facilitate the storage and unloading of materials. The design of silo needs to consider the different problems of materials in the process of storage and unloading and the flow form of materials.

3. Feeding device

The feeding device is responsible for feeding materials evenly and stably into the conveying pipeline. It is usually installed at the beginning of the system, and uses the negative pressure or positive pressure formed by the air source device to mix materials with air in a certain proportion and send them into the pipeline. Common feeding devices include rotary valves, screw conveyors, rotary feeders, screw pumps, silo pumps and Venturi nozzles. The selection of feeding device should be considered comprehensively according to the characteristics of materials and transportation requirements.

4. dust pelletizing system

Dust removal system is very important for the environmental protection performance of Grain granule conveying system system. It is responsible for handling the dust and waste gas generated in the transportation process to ensure that the discharge meets the requirements of environmental protection. Dust removal system usually includes dust collector, fan and discharge pipeline. According to different material characteristics and environmental protection requirements, different dust removal equipment and technical schemes can be selected.

5. Conveying pipeline system

The conveying pipeline is a channel for conveying materials after mixing with airflow. It is made of wear-resistant and corrosion-resistant materials to ensure that the materials will not be polluted or damaged during transportation. The diameter, shape and length of the pipeline will be designed according to the characteristics and delivery capacity of the transported materials. In addition, the pipeline system may also include some auxiliary fittings, such as valves, elbows, expansion joints, etc., for regulating air flow and pipeline connection.

Grain granule conveying system

5、Video analysis of Grain granule conveying system

The following is the live video of Grain granule conveying system designed and produced by hyde for users, from which we can see the the advantage is PLC intelligent control, high degree of automation and simple operation.、In the conveying process, various technological operations can be carried out at the same time.、Materials are transported in a closed pipeline.，Can reduce the pollution to the surrounding environment during transportation, and is fully sealed and pollution-free for transportation.、Remote operation can be carried out from several points to one place or from one place to several points.、High conveying speed, good conveying quality and high conveying efficiency.，meet the needs of material transportation of hyde powderproduction and processing的Grain granule conveying system.。

Grain granule conveying system

As you can see from the live video.，hyde powder it has been widely used in building materials, transportation, machine building, pharmaceutical factory, chemical industry and other industries。

6、Grain granule conveying system price consultation

The Grain granule conveying system price is introduced as follows:

1. product quality

Quality is an important and fundamental factor that affects the price of Grain granule conveying system. In the final analysis, its price depends on its quality. Usually, Grain granule conveying system with better quality will cost more, and such products have better effects, longer service life and more advanced technology. A Grain granule conveying system with a relatively general quality will cost less, have a shorter service life and have a relatively general use effect.

2. Product technology

High-tech products need more advanced technology to support them, so products with higher performance will also lead to a general increase in their prices, and vice versa.

3. product model

The same product, different specifications and models, the performance of the product is different, therefore, manufacturers need different costs in producing and manufacturing products, so the prices of different specifications and models are different, and customers should give priority to suitability when purchasing.

4. Proper management mode

hyde has long used the sales method of small profits but quick turnover to sell products, and the product price, market price and ex-factory price are the same. The purpose of this is to improve the sales volume of products and the visibility of enterprises.

5. market competition

This factor is directly related to the economic dynamics. When the economic dynamics are unstable, the relationship between supply and demand will be unbalanced, which will lead to a very large fluctuation in the price of Grain granule conveying system. Therefore, we should also be aware of the relationship between this factor and the price during the price setting process.

Grain granule conveying system

Grain granule conveying systemIn the process of conveying, various technological operations can be carried out at the same time, such as grade.、The conveying system is closed.，Less affected by climatic and environmental conditions, fully sealed and pollution-free transportation.、Materials collected from several points can be sent to one place or one place to scattered points.、Flexible pipeline layout, closed pipeline can be adjusted according to production conditions, which is relatively flexible.、The material is completely closed in the whole conveying process.，No dust leakage, environmental protection and pollution-free, fully sealed and pollution-free transportation.，the principle is simple.Mainly based on aerodynamic force, the continuous and stable transportation of granular materials is realized in a closed pipeline by using the energy of airflow.。
